3-12
Chapter 3: Configuring the 2085sc-IF16 Using CCW
Name
Module Status
User's Manual Pub. 0300306-01 Rev. A
Length
Type
(Words)
STRUCT
1
Channel Enable or Disable Description
Specify whether to enable use of each selected channel. Each channel is Enabled
by default (checkmark selected).
Data Format Description
The data format allows you to select how analog data is presented. The raw
analog input data is scaled according to the data format selection and the input
range selection. The corresponding range limit is defined in the following tables:
Index Data Format
0
Engineering Unit ×1
1
Engineering Unit ×10
2
Raw/Proportional
3
Percentage Full Scale
Range limits associated with each data format, input range, and signal value are
listed below.
Description
Module Status Bits
Description
Default. The module scales analog input data
to the actual current/voltage values in mA or
mV for the selected input range.
The module scales analog input data to the
actual current/voltage values in mA * 10 or
mV * 10 for the selected input range.
The value presented to the controller is
proportional to the selected input, and scaled
to the maximum data range allowed by the bit
resolution of the ADC.
The value presented to the controller is a
percentage of the user range.
