3-24 Chapter 3: Configuring the 2085sc-IF16 Using CCW

3.3.16 Module Specific General Configuration Errors

Mod_Error Extended_Error_Info
[11:9] [8:0] (hex)
(binary)
010 100
010 101
010 102

Section 3.4 Technical Assistance

Section 3.5 Declaration of
Conformity
User's Manual Pub. 0300306-01 Rev. A
The following table lists module specific general configuration errors for the
2085sc-IF16 module. Bit 8 is set to indicate general configuration errors.
Combined
[11:0]
(hex)
500
501
502
Note that your module contains electronic components which are susceptible to
damage from electrostatic discharge (ESD). An electrostatic charge can
accumulate on the surface of ordinary plastic wrapping or cushioning material. In
the unlikely event that the module should need to be returned to Spectrum
Controls, please ensure that the unit is enclosed in approved ESD packaging
(such as static-shielding / metalized bag or black conductive container).
Spectrum Controls reserves the right to void the warranty on any unit that is
improperly packaged for shipment.
RMA (Return Merchandise Authorization) form required for all product returns.
For further information or assistance, please contact your local distributor, or call
the Spectrum Controls Technical Support at:
For Rockwell Automation Compatible I/O Products:
USA
United Kingdom
Australia
Mexico
Brazil
Europe
Available upon request
Description
General Configuration Error
This error is set if an unexpected configuration
error occurs.
(unused by the 2085sc-IF16)
(unused by the 2085sc-IF16)
440-646-6900
01908 635230
1800-809-929
001-888-365-8677
(55) 11 3618 8800
+49 211 41553 630
