8. The 2085sc-IF16V Configuration dialog appears associated with the
9. To create your configuration using ModuleConfigConverter.exe, refer to
Section 3.3
Setting Configuration
Parameters Using
ModuleConfigConverter.exe
You may create the configuration for each channel using the utility provided by
Spectrum Controls, Inc. You download the utility from the Spectrum Controls
website at www.spectrumcontrols.com.
Chapter 3: Configuring the 2085sc-IF16 Using CCW
selection. You may either manually enter the configuration for your
system, or use the ModuleConfigConverter.exe utility provided by
Spectrum Controls, Inc. Once you have your configuration, you then
copy the data into the Configuration: field:
the section below.
It is recommended that when you generate your configuration, that
NOTE
you use the Binary Radix selection. If you choose the Decimal
Radix, the utility is unable to work with negative values.
User's Manual Pub. 0300306-01 Rev. A
3-5
