Part 2: FPGA Chip

As mentioned above, the FPGA model we use is XC7A200T-2FGG484I,
which belongs to Xilinx's Artix-7 series. The speed grade is 2, and the
temperature grade is industry grade. This model is a FGG484 package with
484 pins. Xilinx ARTIX-7 FPGA chip naming rules as below
Figure 2-1: The Specific Chip Model Definition of ARTIX-7 Series
The main parameters of the FPGA chip XC7A100T are as follows
Logic Cells
CLB flip-flops
Block RAM（kb）
6 / 30
ARTIX-7 SoM FPGA Core Board AC7200 User Manual
Figure 2-2: FPGA chip on board
Name
Slices
Amazon Store:
Sales Email:
Specific parameters
215360
33650
269200
13140
