PIN19 GND
PIN21 B15_L11_P
PIN23 B15_L11_N
PIN25 B15_L1_N
PIN27 B15_L1_P
PIN29 GND
PIN31 B15_L5_P
PIN33 B15_L5_N
PIN35 B15_L3_N
PIN37 B15_L3_P
PIN39 GND
PIN41 B15_L19_P
PIN43 B15_L19_N
PIN45 B15_L20_P
PIN47 B15_L20_N
PIN49 GND
PIN51 B15_L14_P
PIN53 B15_L14_N
PIN55 B15_L21_P
PIN57 B15_L21_N
PIN59 GND
PIN61 B15_L23_P
PIN63 B15_L23_N
PIN65 B15_L22_P
PIN67 B15_L22_N
PIN69 GND
PIN71 B15_L24_P
PIN73 B15_L24_N
PIN75 NC
PIN77 FPGA_TCK
PIN79 FPGA_TDO
Board to Board Connectors CON4
The 80-Pin connector CON4 is used to extend the normal IO and GTP
high-speed data and clock signals of the FPGA BANK16. The voltage standard
25 / 30
ARTIX-7 SoM FPGA Core Board AC7200 User Manual
- Ground
J20 3.3V
J21 3.3V
G13 3.3V
H13 3.3V
- Ground
J15 3.3V
H15 3.3V
H14 3.3V
J14 3.3V
- Ground
K13 3.3V
K14 3.3V
M13 3.3V
L13 3.3V
- Ground
L19 3.3V
L20 3.3V
K17 3.3V
J17 3.3V
- Ground
L16 3.3V
K16 3.3V
L14 3.3V
L15 3.3V
- Ground
M15 3.3V
M16 3.3V
-
V12 3.3V
U13 3.3V
