PIN49 GND
PIN51 B16_L9_P
PIN53 B16_L9_N
PIN55 B16_L11_P
PIN57 B16_L11_N
PIN59 GND
PIN61 B16_L13_P
PIN63 B16_L13_N
PIN65 B16_L15_P
PIN67 B16_L15_N
PIN69 GND
PIN71 B16_L17_P
PIN73 B16_L17_N
PIN75 B16_L19_P
PIN77 B16_L19_N
PIN79 NC
27 / 30
ARTIX-7 SoM FPGA Core Board AC7200 User Manual
- Ground
A15 3.3V
A16 3.3V
B17 3.3V
B18 3.3V
- Ground
C18 3.3V
C19 3.3V
F18 3.3V
E18 3.3V
- Ground
A18 3.3V
A19 3.3V
D20 3.3V
C20 3.3V
-
Amazon Store:
Sales Email:
PIN50 GND
PIN52 B16_L10_P
PIN54 B16_L10_N
PIN56 B16_L12_P
PIN58 B16_L12_N
PIN60 GND
PIN62 B16_L14_P
PIN64 B16_L14_N
PIN66 B16_L16_P
PIN68 B16_L16_N
PIN70 GND
PIN72 B16_L18_P
PIN74 B16_L18_N
PIN76 B16_L20_P
PIN78 B16_L20_N
PIN80 NC
https://www.amazon.com/alinx
rachel.zhou@aithtech.com
- Ground
A13 3.3V
A14 3.3V
D17 3.3V
C17 3.3V
- Ground
E19 3.3V
D19 3.3V
B20 3.3V
A20 3.3V
- Ground
F19 3.3V
F20 3.3V
C22 3.3V
B22 3.3V
-
