3. If using the ADV7183A decoder:
Enable device by driving programmable flag output
Select
(SW5)" on page
4. Program internal registers of the video device in use. Both video
encoder and decoder use a 2-wire serial interface to access internal
registers. The
( ), and
SCL
5. Program the ADSP-BF561 processor's PPI interfaces (configura-
tion registers, DMA, and so on).
Example programs are included in the EZ-KITLite installation
directory to demonstrate the capabilities of the video interface.

Example Programs

Example programs are provided with the ADSP-BF561 EZ-KIT Lite to
demonstrate various capabilities of the evaluation board. These programs
are installed with the EZ-KIT Lite software and can be found in the
...\Blackfin\Examples\ADSP-BF561 EZ-KIT Lite
alDSP++ installation directory. Please refer to the readme file provided
with each example for more information.

Flash Programmer Utility

The ADSP-BF561 EZ-KIT Lite evaluation system includes a Flash Pro-
grammer utility. The utility allows you to program flash memory on the
EZ-KIT Lite. The Flash Programmer is installed with VisualDSP++. Once
the utility is installed, it is accessible from the Tools pull-down menu.
