Table 1-3. LED Connections (Cont'd)

LED Reference Designator

LED7

LED8

An example program is included in the EZ-KIT Lite installation directory

to demonstrate functionality of the LEDs and push buttons.

Example Programs

Example programs are provided with the ADSP-21369 EZ-KIT Lite to

demonstrate various capabilities of the product. The programs are

included in the product installation kit and can be found in the

folder of the installation. Refer to a readme file provided with each exam-

ple for more information.

CCES users are encouraged to use the example browser to find examples

included with the EZ-KIT Lite Board Support Package.

file containing all of the electronic information required for the

.zip

design, layout, fabrication and assembly of the product is available for

download from the Analog Devices board design database at:

http://www.analog.com/sharc-board-design-database

ADSP-21369 EZ-KIT Lite Evaluation System Manual

Using the ADSP-21369 EZ-KIT Lite

Processor Pin

DAI16

FLAG3/TMREXP/MS3

Examples

1-17
