communication between the host PC and target hardware. Analog Devices
carries a wide range of in-circuit emulation products. To learn more about
Analog Devices emulators and processor development tools, go to
http://www.analog.com/dsp/tools/
The ADSP-BF561 EZ-KIT Lite provides example programs to demon-
strate the capabilities of the evaluation board.
The ADSP-BF561 EZ-KIT Lite installation is part of the Visu-
alDSP++ installation. The EZ-KIT Lite is a licensed product that
offers an unrestricted evaluation license for the first 90 days. For
details about evaluation license restrictions after the 90 days, refer
to "Evaluation License Restrictions" on page 1-7
alDSP++ Installation Quick Reference Card.
The board features:
• Analog Devices ADSP-BF561 Blackfin processor
256-pin mini-BGA package
30 MHz
• Synchronous dynamic random access memory (SDRAM)
64 MB (16M x 16 bits x 2 chips)
• Flash memory
8 MB (4M x 16 bits)
• Analog audio interface
AD1836 A – Analog Devices 96 kHz audio codec
4 input RCA phono jacks (2 stereo channels)
6 output RCA phono jacks (3 stereo channels)
x
www.BDTIC.com/ADI
.
oscillator
CLKIN
