Part Description
IDC header
IDC socket

SPI (P5)

The SPI connector is linked to a 12-pin connector. The connector's
pinout can be found in
page
B-1.
Part Description
IDC header
IDC socket

JTAG (ZP4)

The JTAG header is the connecting point for a JTAG in-circuit emulator
pod. When an emulator connects to the JTAG header, the USB debug
interface is disabled.
Pin 3 is missing to provide keying. Pin 3 in the mating connector
should have a plug.
When using an emulator with the EZ-KIT Lite board, follow the
connection instructions provided with the emulator.
ADSP-BF561 EZ-KIT Lite Evaluation System Manual
www.BDTIC.com/ADI
ADSP-BF561 EZ-KIT Lite Hardware Reference
Manufacturer
FCI
Mating Connectors
DIGI-KEY
"ADSP-BF561 EZ-KIT Lite Schematic" on
Manufacturer
SULLINS
Mating Assembly
DIGI-KEY
Part Number
68737-420HLF
S4210-ND
Part Number
GEC06DAAN
S4207-ND
2-21
