Jumper and DIP Switch Settings

Jumper and DIP Switch Settings
This section describes functionality of the jumpers and DIP switches. The
jumper and DIP switch locations are shown in
Figure 2-2. DIP Switch Locations

Video Configuration Switch (SW2)

The video configuration switch (
from the ADV7183A video decoder and ADV7179 video encoder are
routed to the processor's PPIs. The switch also determines if the
controls the
~OE
Table 2-4.
2-10
www.BDTIC.com/ADI
SW2
signal of the ADV7183A video decoder outputs. See
ADSP-BF561 EZ-KIT Lite Evaluation System Manual
Figure 2-2.
) determines how some video signals
pin
PF2
