5.1.3 Hardware Specifications

Specification
Backplane Current Load
Operating Temperature
Storage Temperature
Shock
Relative Humidity
LED Indicators
4-Character, Scrolling, Alpha-
Numeric LED Display
Debug/Configuration/Application Ethernet port (E1)
Ethernet Port
Shipped with Unit
Page 96 of 159
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
Description
800 mA @ 5 Vdc
3 mA @ 24 Vdc
0° C to 60° C (32° F to 140° F)
-40° C to 85° C (-40° F to 185° F)
30 g operational
50 g non-operational
Vibration: 5 g from 10 to 150 Hz
5% to 95% (without condensation)
Battery Status (ERR)
Application Status (APP)
Module Status (OK)
Shows Module, Version, IP, Application Port
Setting, Port Status, and Error Information
10/100 Base-T, RJ45 Connector, for CAT5 cable
Link and Activity LED indicators
Auto-crossover cable detection
5-foot Ethernet straight-through cable
