MVI56E-MNETCR ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
Make a note of the slot location. You must identify the slot in which the
4
module is installed in order for the sample program to work correctly. Slot
numbers are identified on the green circuit board (backplane) of the
ControlLogix rack.
Turn power ON.
5
Note: If you insert the module improperly, the system may stop working or may behave
unpredictably.
