3.1.2 Command Control Data Object (MNETCCONTROL)

Values used by program for data transfer operation between the module and the
processor.
Name
BootTimer
WarmBoot
ColdBoot
EventCmdTrigger
EventCmdPending
ClientID
EventCmd
CmdControl
CmdControlTrigger
CmdControlPending
IPAddress
WriteCmdBits
Event Command Data Object (MNETCREVENTCMD)
The Event object is not placed in the module definition object and is only required
when event commands are utilized in the application. This structure holds the
information required for an event command. An array of these objects should be
defined and hold the event command set to be employed in the application. The
following illustration shows the structure of the object.
Name
IP0
IP1
IP2
IP3
ServPort
SlvAddrNode
DBAddress
Count
Swap
MBFunction
Address
Page 74 of 159
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
Data Type
TIMER
BOOL
BOOL
BOOL
BOOL
INT
MNETCREVENTCMD
(page 74)
MNETCRCMDCONTROL
(page 75)
BOOL
BOOL
MNETCRIPADDRESS
(page 75)
INT[30]
Data Type Description
INT First digit of IP address
INT Second digit of IP address
INT Third digit of IP address
INT Last digit of IP address
INT TCP Service Port number (0-65535), 502 for MBAP,
2000 for MNET
INT Modbus slave node address (0 to 247)
INT Module internal database to use with message
INT Register or data point count
INT Swap code to use with functions 3 and 4
INT Modbus function code for message
INT Address to interface with in device
MVI56E-MNETCR ♦ ControlLogix Platform
Description
Timer used to clear both cold and warm
boot requests
Hardware reset of the Module
Configuration data reset in the Module
Initiates Event Command.
Allows Event Command.
Client ID to poll a server with the Event
Command.
Holds Event Command configuration
Holds Command Control status
Initiates Command Control.
Halts rung until Module is ready
IP address statistics including triggers
Selects individual clients to to activate its
commands.
