Connecting Your Pc To The Module - ProSoft Technology inRAX MVI56E-MNETCR User Manual

MVI56E-MNETCR ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
1.7

Connecting Your PC to the Module

With the module securely mounted, connect one end of the Ethernet cable to the
Config (E1) Port, and the other end to an Ethernet hub or switch accessible from
the same network as your PC. You can also connect directly from the Ethernet
Port on your PC to the Config (E1) Port on the module by using an Ethernet
crossover cable (not included).
