Module Data Object (Mnetcrmoduledef) - ProSoft Technology inRAX MVI56E-MNETCR User Manual

Ladder Logic
User Manual
3.1

Module Data Object (MNETCRMODULEDEF)

All data related to the MVI56E-MNETCR is stored in a user defined data type. An
instance of the data type is required before the module can be used. This is done
by declaring a variable of the data type in the C
dialog box. The following table describes the structure of this object.
Name
DATA
CONTROL
STATUS
UTIL
This object contains objects that define the configuration, user data, status and
command control data related to the module.
Page 72 of 159
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
Data Type
MNETCRDATA (page
73)
MNETCRCONTROL
(page 74)
MNETCRSTATUS
(page 75)
MNETCRUTIL (page
77)
MVI56E-MNETCR ♦ ControlLogix Platform
T
ONTROLLER AGS
Description
Data read from module
MNETCR Module control
Client ,Server Status and blocks status
Block statistics
E T
DIT AGS
ProSoft Technology, Inc.
June 14, 2011
