ProSoft Technology inRAX MVI56E-MNETCR User Manual page 101

MVI56E-MNETCR ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
Status Read Data Block IDs 0 and -1
This block is automatically copied from the module into the MNETCR.STATUS
array when the block ID is 0 or -1, and contains status information about the
module.
Offset
0
1
2 to 7
8 to 37
38 to 40
41
Status Data Block Structure
This section contains a description of the members present in the
MNETCR.STATUS array. This data is transferred from the module to the
processor as part of each read block.
Offset Content
1 Pass Count
2 Read Block Count
3 Write Block Count
4 Parse Block Count
5 Command Event Block
Count
6 Command Block Count This field contains the total number of command blocks
7 Error Block Count
8 to 37 Enable/Disable
Command Bits
ProSoft Technology, Inc.
June 14, 2011
Description
Write Block ID
Program Scan Counter
Block Transfer Status; Read, Write, Parse, Command,
Event and Error Counts
Client 0 to Client 29 Command Execution Control Bits
Reserved
Read Block ID (-1 or 0)
Description
This value is incremented each time a complete program
cycle occurs in the module.
This field contains the total number of read blocks
transferred from the module to the processor.
This field contains the total number of write blocks
transferred from the processor to the module.
This field contains the total number of blocks successfully
parsed that were received from the processor.
This field contains the total number of command event
blocks received from the processor.
received from the processor.
This field contains the total number of block errors
recognized by the module.
Each bit in each word is used to enable or disable individual
commands in each client
Reference
User Manual
Length
1
1
6
2
17
1
