Ladder Logic
User Manual
Block Statistics Object (MNETCRBLOCKSTATS)
This object contains a structure that includes the status information for the data
transfer operations between the processor and the module. The following table
describes the structure of this object.
Name
Read
Write
Parse
Event
Cmd
Err
Client Statistics Object (MNETCRCLIENTSTATS)
This block also contains a structure that includes Client statistics. The following
table describes the structure of this object.
Name
CmdReq
CmdResp
CmdErr
Requests
Responses
ErrSent
ErrRec
CfgErrWord
CurErr
LastErr
Refer to MVI56E-MNETCR Status Data Definition (page 105, page 112) for a
complete listing of the data stored in the status object.
Page 76 of 159
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
Data Type
Description
INT
Total number of read block transfers
INT
Total number of write block transfers
INT
Total number of blocks parsed
INT
Total number of event blocks received
INT
Total number of command blocks received
INT
Total number of block transfer errors
Data Type
Description
INT
Total number of command list requests sent
INT
Total number of command list responses received
INT
Total number of command list errors
INT
Total number of requests for port
INT
Total number of responses for port
INT
Total number of errors sent
INT
Total number of errors received
INT
Configuration Error Word
INT
Current Error code
INT
Last recorded error code
MVI56E-MNETCR ♦ ControlLogix Platform
ProSoft Technology, Inc.
June 14, 2011
