ProSoft Technology inRAX MVI56E-MNETCR User Manual page 108

Reference
User Manual
Set Module IP Address Block (9990)
IP Set Request (Write Block)
Offset
0
1
2
3
4
5 to 41
IP Set Response (Read Block)
Offset
0
1
2
3
4
5
6 to 41
Page 108 of 159
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
Description
9990
First digit of dotted IP address
Second digit of dotted IP address
Third digit of dotted IP address
Last digit of dotted IP address
Reserved
Description
0
Write Block ID
First digit of dotted IP address
Second digit of dotted IP address
Third digit of dotted IP address
Last digit of dotted IP address
Spare data area
MVI56E-MNETCR ♦ ControlLogix Platform
Length
1
1
1
1
1
36
Length
1
1
1
1
1
1
35
