4.3

Reading Status Data from the Module

The MVI56E-MNETCR module maintains a Status Data Table that can be used
to determine the module's operating status. This data is located in the module's
database at the location specified by the Error Status Pointer configuration
parameter (page 50). This data is transferred to the processor continuously. For
a complete listing of the status data object, refer to Status Data Definition (page
105, page 112).
The Configuration/Debug port provides the following functionality:
Full view of the module's configuration data
View of the module's status data
Complete display of the module's internal database (registers 0 to 3999)
Version Information
Control over the module (warm boot, cold boot, transfer configuration)
Facility to upload and download the module's configuration file
