MVI56E-MNETCR ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
Command Control Data Object (MNETCRCMDCONTROL)
MVI56E-MNETCR Command Control
Name
ClientIDreq
CmdQty
CmdIndex
IP Address Object (MNETCRIPADDRESS)
This object holds IP address status with set IP & get IP triggers.
Name
IPgetTrigger
IPreceived
IPsetTrigger
IPrequested

3.1.3 Status Object (MNETCRSTATUS)

This object contains the status of the module. The MNETCRSTATUS object is
updated each time a read block is received by the processor. Use this data to
monitor the state of the module at a "real-time rate".
Name
PassCnt
BlockStats
CmdBits
ClientStatsTrigger
ClientIDReq
ClientStatus
ClientIDRec
CmdErrorList
ClientStatsPending
ProSoft Technology, Inc.
June 14, 2011
Data Type Description
INT Requested Client ID.
INT Command Quantity for the Client.
INT[16] Command Index per client. (0 to 15)
Data Type Description
BOOL Triggers get IP address.
INT[4] Displays received IP address.
BOOL Triggers set IP address
INT[4] Displays requested IP address
Data Type
INT
MNETCRBLOCKSTATS
(page 76)
INT[30]
BOOL
INT
MNETCRCLIENTSTATS[30]
(page 76)
INT
INT[16]
BOOL
Description
Program cycle counter
Block Statistics
Commands bits array to be used for 30
clients
Get Client Status
Client ID requested.
Client Status requests
Client ID received.
Command Error List
Allows Get Client Status
Ladder Logic
User Manual
Page 75 of 159
