Diagnostics and Troubleshooting

In This Chapter
LED Status Indicators ............................................................................ 80
Using the Diagnostics Menu in ProSoft Configuration Builder ............... 84
Reading Status Data from the Module .................................................. 91
The module provides information on diagnostics and troubleshooting in the
following forms:
LED status indicators on the front of the module provide information on the
module's status.
Status data contained in the module can be viewed in ProSoft Configuration
Builder through the Ethernet port.
Status data values are transferred from the module to the processor.
