MVI56E-MNETCR ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communications Module for Remote Chassis
5

Reference

In This Chapter
Product Specifications ........................................................................... 94
Functional Overview .............................................................................. 97
Data Flow between MVI56E-MNETCR Module, Processor, and Network
............................................................................................................ 111
Ethernet Cable Specifications ............................................................. 116
Modbus Protocol Specification ............................................................ 118
Using the Optional Add-On Instruction Rung Import ........................... 132
Adding the Module to an Existing Project ............................................ 142
Using the Sample Program - RSLogix 5000 Version 15 and earlier .... 145
ProSoft Technology, Inc.
June 14, 2011
Reference
User Manual
Page 93 of 159
