Deploying the VOIP Network

Deploying the VOIP Network
For a Proprietary Phone Directory database, the VOIP
administrator can deploy the pre-configured Client MultiVOIP
200s to their remote sites. The remote site administrators need
only connect power to the pre-configured MultiVOIP 200,
connect the MultiVOIP 200 to their Ethernet LAN and
predefined telephone equipment, and then wait for the phone
directory database to be downloaded.
With the Gatekeeper option enabled on the Phone Directory
Database dialog box, all MultiVOIP 200s are configured as
"Host" and cannot be downloaded. In this case, each
MultiVOIP 200 Phone Book will be programmed with phone
numbers for its own channels. These phone numbers are
registered with the H.323 Gatekeeper (See the "Registering
with a Gatekeeper Phone Directory" section discussed earlier.)
