If you are connecting an E&M trunk from a telephone
switch to your MultiVOIP 200, connect one end of an RJ-
45 phone cord to the Voice/Fax Channel 1 E&M
connector on the back of the unit and the other end to the
trunk phone jack.
If you are connecting to an E&M trunk, you need to ensure
that the E&M trunk jumper is in the correct position for the
E&M type trunk. The default E&M jumper position is E&M
type 2. To change the E&M jumper position, perform the
E&M jumper block positioning procedure.
5. Repeat the above step to connect the remaining telephone
equipment to each Voice/Fax Channel on your MultiVOIP.
6. Turn on power to the MultiVOIP 200 by placing the ON/
OFF switch on the back panel to the ON position. Wait for
the BOOT LED on the MultiVOIP 200 to go OFF before
proceeding. This may take a couple of minutes.
7. At this time your VOIP network should be fully operational.
Dial one of the sites in your network.
Deploying the VOIP Network
63
