MultiVOIP Quick Start Guide
3. Connect a network cable to the Ethernet 10Base-T
connector on the back of the MultiVOIP 200. Connect the
other end of the cable to your network.
4. If you are connecting a station device; e.g., analog
telephone, fax machine, or Key Telephone System (KTS)
to your MultiVOIP 200, connect the smaller end of a
special adapter cable (supplied) to the Voice/Fax Channel
1 FXS connector on the back of the MultiVOIP 200 and the
other end to the station device.
If you are connecting a PBX extension to your MultiVOIP
200, connect the smaller end of a special adapter cable
(supplied) to the Voice/Fax Channel 1 FXO connector on
the back of the MultiVOIP 200 and the other end to the
PBX extension.
If you are connecting an E&M trunk from a telephone
switch to your MultiVOIP 200, connect one end of an RJ-
45 cable (not supplied) to the Voice/Fax Channel 1 E&M
connector on the back of the MultiVOIP 200 and the other
end (8 spade lugs or 8 wires to connect directly to the
punch-down block) to the PBX trunk card.
Note: For customers building their own E&M connector,
App. B of the User Guide has a pinout diagram showing
the E&M back panel connector on the MultiVOIP 200.
5. Repeat step 4 to connect the remaining phone equipment
to each Voice/Fax Channel on your MultiVOIP 200.
6. Turn on power to the MultiVOIP 200 by setting the power
switch on the back panel to the 1 (up, On) position. Wait for
the Boot LED on the MultiVOIP 200 to go Off before
proceeding. This may take a couple of minutes.
If you need to change the E&M Jumper Block positioning,
refer to the following section; otherwise, proceed to the
Software Loading section to load MultiVOIP 200 software.
