Haldex DIAG++ Operator's Manual page 77

Operator's Guide
Saving the ECU parameters
Saving the ECU parameters to disc
In ECU configuration dialog click on Save ECU
configuration to file button.
This will throw up a Windows Explorer dialog.
The suggested filename (based on VIN) can be altered
if required.
File is saved as a .dpf file type when Save button clicked
(default save directory is C:\Program Files\Haldex\
Diag++\ECU setup files).
Note: The saved .dpf file can be used to program other
EB+ 4.0 EBS (with same configuration) by clicking
on Load ECU configuration from file button and
selecting the relevant .dpf file – then programming that
configuration into the EB+ 4.0 EBS.
Programming the ECU.
In ECU configuration dialog click on Program ECU
configuration button.
This will start the programming of the configuration to
the ECU.
(The configuration can be obtained from a loaded .dpf
file or setup manually via Edit configuration dialog.)
During programming a progress dialog is thrown up.
This displays both a progress bar and informational
messages on programming progress.
Note: after programming all active DTCs are deleted
and the ECU is reset.
During programming the trailers EBS warning lamp will
flash.
