Operator's Guide
For full trailers the following screen will appear.
The following example shows values entered from a
Haldex brake calculation as shown below.
Brake calculation example - Master ECU (RAG)
Input data for the EBS-Modulator EB+:
RAG
control pr. pm
Axle Axle load Bag press.
unladen unladen
(Kg) (bar)
1 1700 0.55
2022
DIAG++ DIAG++
control pr.
6.50 bar
Brake press.
unladen
(bar)
1 12
2.10
Innovative Vehicle Solutions
pm
Axle load Bag press.
laden laden
(Kg) (bar)
2
9000 3.50
3
4 10
P0 PD P3
0.40 0.70 6.50 bar
Brake press.
laden
(bar)
5 11
0.00 0.40 6.85 bar
