Haldex DIAG++ Operator's Manual page 44

Premium EBS auxiliary operation
AUX 4 / AUX 5
Lining wear sensor
General purpose input
Control line sensor
Mechanical height
sensor
Mechanical height
sensor remote
External pressure sensor
44
DIAG++
AUX 1 - 3
COLAS+
Retarder
Trailer lamp
ILAS-E+ front
ILAS-E+ rear
AUX power
Steer axle lock
Service lamp
Overload lamp
Remote overload lamp
Stability lamp
ILAS-E+ front manual
ILAS-E+ rear manual
General purpose output
TA+
Speed lock
TPMS lamp
