Operator's Guide

Auxiliary operation

Auxiliary operations are dependant on the installed EBS product.
EB+ 4.0 has up to 4 usable Premium auxiliary connectors (AUX 0-3), 2 usable Standard auxiliary connectors (AUX
4 & 5) and a Super AUX, which can be configured using the DIAG++ software.
This amount of inputs and outputs are sufficient for most used standard trailer applications. In the case of
malfunction (short circuit / open circuit) the EB+ 4.0 system generates a DTC code and the service lamp will be
triggered after start up.
EBS variant
Basic EBS
(without emergency override)
Basic EBS
Premium EBS
AUX function assignment
Wire colour
Red
Black
Yellow
Key:
O/P (AUX 0-3) – Switched supply voltage outputs on red channel (pin 1) and yellow channel (pin3) with 1.2A
maximum supply current for each channel.
Dig I/ P (AUX 0) - Digital monitor input. Both red channel (pin 1) and yellow channel (pin 3) can be used to
monitor a state of change input (B+ or B-)
Dig I/P (AUX 0-3) – Digital monitor input. Red channel (pin 1) can be used to monitor a state change input (B+ or
B-)
Ana I/P (AUX 1-3) – Analogue input on yellow channel (pin 3) can be used to measure voltage input.
Ana I/P (AUX 4 & 5) – Analogue input. Analogue input (pin 3) between 0 and 5V.
5 volt (AUX 4 & 5) – 5 volt switched output on pin1. Combined supply current from AUX 4 and AUX 5 (pins 1)
must not exceed 50mA
B- – System ground connection (pin 4)
2022
DIAG++ DIAG++
AUX 0 AUX 1 AUX 2
  
  
  
AUX 0 AUX 1 AUX 2
O/P DIG O/P DIG O/P DIG
I/P I/P I/P
B- B- B-
O/P DIG O/P O/P
I/P ANA I/P ANA I/P
Innovative Vehicle Solutions
AUX 3 AUX 4 AUX 5
  
  
  
AUX 3 AUX 4 AUX 5
O/P DIG
5 Volt 5 Volt
I/P
B- B- B-
O/P
ANA I/P ANA I/P
ANA I/P
Super
AUX



