Haldex DIAG++ Operator's Manual page 42

Secondary load plate settings
Click on 'Secondary' icon (if available) to display this
load plate.
The following example shows values entered from a
Haldex brake calculation as shown below.
Brake calculation example - Remote ECU FAG)
Input data for the EBS-Modulator EB+:
FAG
control pr. pm
Axle Axle load Bag press.
unladen unladen
(Kg) (bar)
1 2350 0.70
42
control pr.
6.50 bar
Brake press.
unladen
(bar)
1
12
2.10 10000
Innovative Vehicle Solutions
DIAG++
Secondary load plate tab
pm
Axle load Bag press.
laden laden
(Kg) (bar)
2
5.00
Operator's Guide
3 8 10
4 6
P0 PD P1 P2
0.20 0.70 2.00 2.50 6.50 bar
Brake press.
laden
(bar)
5 7 9
0.00 0.50 1.40 2.50 6.85 bar
P3
11
2022
