Haldex DIAG++ Operator's Manual page 21

Operator's Guide
Options
Item Option description
1 EB+ 4.0 assembly
2 ISO 7638 7-pin socket assembly
3 ISO 12098 junction box
4 Sensor
5 COLAS+
6 ILAS®-E+
7 Lining Wear System (LWS)
EB+ Soft Docking
8
TPMS
9 Telematics
10 Customer specific ECU
11 Traction help switch
Connecting cables
Item Option description
C1 Power B with Super AUX to junction box
C2 Sensor extension
C3 Auxiliary DIN
C4 Auxiliary DIN
C5 Auxiliary DIN
Auxiliary Y-Splitter 3x2x2 way
C6
(Premium AUX) M/F/F
C7 CAN to EB+ Soft Docking
C8 CAN Y- Splitter (M/F/F)
C9 CAN to Y-Splitter
C10 ISO 7638 diagnostic
C11 PC interface
C12 Dongle USB cable
C13 Customer specific ECU
2022
DIAG++ DIAG++
Part No.
842 014 001
844 001 XXX
N/A
364 094 000 2
338 061 201
338 071 101
352 080 001
844 361 0002
See SD Guide
See TPMS Guide
N/A
N/A
844 351 XXX
844 352 XXX
Part No.
844 221 XXX
844 401 XXX
844 321 XXX
844 321 XXX
844 321 XXX
844 342 001
844 571 XXX
844 542 XXX
844 521 001
815 018 001
814 011 001
042 7073 09
Innovative Vehicle Solutions
Notes
Premium with Mobiliser shown
ISO 7638 7-pin socket to EB+ 4.0
Customer supplied junction box
Right angled sensor
Single circuit
Dual circuit
Programmable via DIAG++
Programmable via DIAG++
Programmable via DIAG++
Programmable via DIAG++
Rear mount
Front mount
Notes
Junction box to EB+ 4.0
Sensor assembly to EB+ 4.0
COLAS+ to EB+ 4.0
ILAS-E+ to Y-Splitter
ILAS-E+ to Y-Splitter
Y-Splitter to EB+ 4.0 AUX1
EB+ Soft Docking to EB+ 4.0
Telematics to
Y-Splitter - DIN interface
PC Interface to
ISO 7638 diagnostic
Remote PC to
DIAG++ PC Interface
Customer specific ECU to
CAN Y Splitter
