From the Gain drop-down list, set the maximum gain in 3db steps from Off to 54dB.
Increasing the gain lightens dark pictures resulting from low-level lighting. The default
setting is 36dB.
Click SET.

Picture Adjustment

Adjustment of some qualities of the video is made possible by selecting Picture Adjustment in the
Camera tab. Brightness, Sharpness, Contrast, Saturation and Hue may all be adjusted via drop-down
menus from this window, as shown below.
Brightness
You can adjust the image's brightness by adjusting this parameter. Select from the range between
+1 to +25. To increase video brightness, select a larger number. The default setting is 0. Click SET to
confirm the new setting.
Sharpness
Increasing the sharpness level can make the image look sharper, especially enhancing the object's
edge. Select from the range between -15 to +10 in 1dB steps. The default setting is -10. Click SET to
confirm the new setting.
April 25, 2017
Manual Mode
Fixed Shutter Speeds
PAL
1/10000
1/3500
1/2500
1/1750
1/1250
1/1000
1/600
1/425
1/300
1/215
1/150
1/120
1/100
1/75
1/50
1/25
1/12
Figure 70: Camera Settings Screen – Picture Adjustment
CF-5212/CF-5222 User and Installation Guide
NTSC
1/10000
1/4000
1/3000
1/2000
1/1500
1/1000
1/725
1/500
1/350
1/250
1/180
1/125
1/100
1/90
1/60
1/30
1/15
Configuration and Operation
