3. Align the lens threads into the lens mount and screw in the lens.
4. If your lens has a DC auto iris, plug the auto iris cable from the lens assembly into the
AUTO IRIS port of the camera.
Tip:
If there are problems focusing, it might be necessary adjust the back focus. See
Focus Adjustment
April 25, 2017
Figure 6: Installed C-CS Mount
Figure 7: Auto Iris Port Connection
(page 119).
CF-5212/CF-5222 User and Installation Guide
Installation
Back
19
