Configuration and Operation
9. Select the Auto > Step 2: Verification tab.
10. Verify that the horizon, camera height, and human marker settings are correct.
Note:
If the results are unsatisfactory, run Auto Calibration again (follow Step #1 on-screen) or
click MANUAL to manually configure the depth settings.
11. After finishing the Auto Configuration, click the MANUAL tab.
12. Select the Manual > Step 4: Verification tab to complete the depth configuration.
Manual Depth Calibration
If you select the MANUAL depth button, there are two methods to manually configure depth settings:
If you are performing setup by yourself, click the Solo Setup tab.
If you are not performing setup alone, proceed to
Note:
1. It is possible to select the Step 4: Verification tab to verify and apply settings at any
time.
2. For detailed instructions how to set markers and guidelines, follow instructions in the
HTML Edition Units User's Guide.
Solo Setup
The Solo Setup function enables you to install and setup the camera at a remote site without requiring
another person's assistance. It is very useful and should be used even if you have another person's
assistance.
With this feature, you can:

Move around within the camera's Field of View.

Use the camera to record a set of snapshots of the scene while the user is moving around the
camera Field of View. Creating the recording of the person in the FoV can be used to adjust
settings without requiring another physical walk through the FoV.

Use the recording of his movement to setup the depth by marking his height on the camera's
Field of View.
88 CF-5212/CF-5222 User and Installation Guide
Configuring Ground and Height Settings.
