Figure 9: Dna Assign Ip Dialog Box - FLIR CF-5212 User And Installation Manual

Right-click the mouse and select the assigned IP address or click the Assign IP
button to open the DNA Assign IP dialog box.
Note:
The camera default IP Address and the subnet mask IP Address are automatically
supplied by the DHCP server.
In the dialog box that is displayed, enter values for the IP Address, Gateway and
Netmask.
Click Update and wait for
Disconnect the Ethernet cable. The camera is ready for deployment (mounting) in a
site installation.
Note:
Tip:
A camera setup adapter, such as Veracity Pinpoint, can be used to connect a laptop
directly to the camera when using PoE.
April 25, 2017
1. The camera can be connected to a PC for bench installation via an Ethernet
cross-cable.
2. The camera default IP Address is automatically set by the DHCP server. If
using Latitude, the Address must be set manually.
CF-5212/CF-5222 User and Installation Guide
OK status to be displayed.

Figure 9: DNA Assign IP Dialog Box

Installation
21
