Installation

5.3 Initial Camera Configuration

Caution:
If you are using Latitude, we recommend that you configure the camera's settings via the
AdminCenter. This is because the camera's web-based interface might be overwritten by Latitude
settings. Refer to the Latitude online help for information regarding configuring camera settings.
Attention:
Si vous utilisez Latitude, nous vous conseillons de configurer les paramètres de la caméra via
l'AdminCenter. En effet, l'interface Internet de la caméra peut être remplacée par les paramètres
Latitude. Veuillez consulter l'aide en ligne Latitude pour de plus amples informations sur la
configuration des paramètres de la camera.
To perform the initial camera configuration
1. Unpack the camera and remove the protective cover.
2. Connect one end of the network Cat 5 Ethernet cable to the RJ45 connector on the
camera's connector panel.
3. Connect the other end of the network cable to a Power Sourcing Equipment (PSE)
device, such as a switch.
4. Verify that the LEDs on the RJ45 connector illuminate green (indicating a stable network
connection) and flashing yellow (to indicate network activity).
5. Do the following:
Copy and run dna.exe (see note below) from the included CD.
Note:
DNA is a user-friendly utility that is designed to easily discover and configure FLIR
edge devices on a network. The IOI HD fixed camera is supported by DNA version
2.0.4.8 and above. For instructions how to use DNA, click
User Manual from the Tools section.
Click the
Select the unit requiring IP assignment.
20
icon.

Figure 8: Discovered IP Devices

CF-5212/CF-5222 User and Installation Guide
here to download the DNA
April 25, 2017
