FLIR Quasar CM-6405 Quick Install Manual

1 Check Contents
Make sure all of the items above are included in the camera kit.
2 Select a Location
Select a suitable location to mount the camera.
Verify that the operating temperature range is in the following ranges, with no
more than 90% non-condensing humidity:
·
With heater: -55° C to 60° C (-67° F to 140° F)
·
Cold start with heater: -55° C to 60° C (-67° F to 140° F)
Warnings
·
Placing a camera in a surrounding environment subject to extremely high
temperature can result in an explosion or the leakage of flammable liquid or
gas.
·
Subjecting the camera to extremely low air pressure can result in an explosion
or the leakage of flammable liquid or gas.
·
The camera must be installed by qualified personnel and the installation
should conform to all local codes.
Be sure to have the required accessories and tools available and refer to the
camera's installation and user guide as necessary.
Cables can enter the camera either through the rear of the camera via the
mounting bracket or through a conduit hole on the side of the camera. If the cables
enter through the rear, make sure that the location provides a suitable method for
routing the cables.
CM-6405 / CM-6408 Quick Install Guide Revision 120
This document does not contain any export-controlled information.
Quasar™ Mini-Dome
CM-6405 / CM-6408
Quick Install Guide
December 2021
