CompAir 5280D.1.IAC Operator's Handbook Manual page 92

48000 HOURS
SERVICE
Change oil & oil filter element.
Change suction filter element.
Replace bursting disc.
Replace 3
Service 1
Service non-return valve.
Replace DDV diaphragm and joint.
Replace 1
Replace connecting rod bolts, nuts & washers.
PARTS REQUIRED
Mineral oil - 20 litres. (total capacity 50 litres)
Oil filter
Suction filter element
Bursting disc kit
Service kit 1
Service kit 2
rd
3 stage piston ring kit
Service kit 3
'O' ring kit valve maintenance
Fibre washers
Non-return valve service kit
Washer for strainers
Joint for gland door
Joint for crankcase door
DDV diaphragm
DDV joint
st
1 stage suction valve unloader diaphragm.
nd
2 & 3
Connecting rod bolt
Connecting rod nut
Connecting rod washer
RECOMMENDED SERVICE PLAN – 5280D.1-M
5280D - MINERAL OIL
IMPORTANT - DAILY & BEFORE STARTING
CHECK OIL LEVEL TOP UP AS NECESSARY.
rd
stage piston ring set.
st nd rd
, 2 & 3 stage valve's.
st nd rd
, 2 & 3 stage suction valve unloader diaphragms.
st
stage valve
nd
stage valve
rd
stage valve
rd
stage suction valve unloader diaphragm.
RSP5280DM.7
CompAir UK Ltd
Page 5
No Off Part Ref
3 98384.1029
1 98262.199
1 98262.1019
1 C201556.100
1 98650.2007
1 98650.1827
1 98477.1153
1 98650.1833
1 98504.1383
2 C66210.30
1 98650.1940
3 98504.1417
2 C10190-103
1 C10190-101
1 C201843
1 C201839
4 C20000-37
2 98650.1782
4 C10190-29
4 C10190-266
4 C10190-30
5280D:m.doc
