CompAir 5280D.1.IAC Operator's Handbook Manual page 111

2.2.9.3 Test analogue inputs
Input Parameter
1 System pressure
2 Oil pressure
3 Spare
4 Cylinder cooling water temp.
5 Ist stage delivery temperature
nd
6 2 stage delivery temperature
rd
7 3 stage delivery temperature
8 Final air delivery temperature
st
9 1 stage pressure
nd
10 2 stage pressure
rd
11 3 stage pressure
12 Spare
2.2.9.4 Test displays
Parameter
Display test All digits of all the displays and all LEDS are lit up at the same time for testing.
2.2.9.5 Test keyboard
Parameter
Test keyboard When a push button is pushed, its function is shown on the alphanumeric display.
By waiting 3 seconds after pushing all the buttons, this menu can be left.
98155.1015
App 408 Customer PET controller installation guide & user's manual
The applied voltage of the analogue input 1 is displayed. 0-5 volts
The applied voltage of the analogue input 2 is displayed. 0-5 volts
The applied voltage of the analogue input 3 is displayed. 0-5 volts
The applied voltage of the analogue input 4 is displayed. 0-5 volts
The applied voltage of the analogue input 5 is displayed. 0-5 volts
The applied voltage of the analogue input 6 is displayed. 0-5 volts
The applied voltage of the analogue input 7 is displayed. 0-5 volts
The applied voltage of the analogue input 8 is displayed. 0-5 volts
The applied voltage of the analogue input 9 is displayed. 0-5 volts
The applied voltage of the analogue input 10 is displayed. 0-5 volts
The applied voltage of the analogue input 11 is displayed. 0-5 volts
The applied voltage of the analogue input 12 is displayed. 0-5 volts
Function
Function
Function
Page 15
Table 13
Table 14
Table 15
App 408C
