Crankcase - 3 - CompAir 5280D.1.IAC Operator's Handbook Manual

REF. NO PART No
C20010.55
1 C10190.63
2 C20010.47
3 C10190.98
4 C10530.315
5 C10190.588
6 C10190.590
7 A6450.104
8 C10190.745
9 C10190.762
10 A4341.250
11 A4334.93
12 A4330.62
13 A4322.6
CompAir UK Ltd

CRANKCASE - 3

PARTS LIST
DESCRIPTION
CRANKCASE
BEARING HOUSING
BEARING HOUSING
JOINT
RETAINER
MAIN BEARING
WASHER
OIL SEAL
CARRIER RING
BAFFLE
CAPSCREW
HEX HD SCREW
STUD
NUT
5280D Compressor Publication 98407.1440
No OFF
1
1
1
2
2
3
2
1
1
1
6
8
8
8
Page 43
1440.doc
