3 Technical specifications
Power supply
Internal power supply digital inputs
Internal power supply analogue inputs
Internal power supply electronic
outputs
PWM outputs (Not used)
Frequency
Pulse width
Internal power supply analogue inputs
Relays
Operating temperature
Storage temperature
Rel. humidity at 40C at front side
Rel. humidity at 40C at rear side
Operating vibrations over 10 to 150Hz
Transport vibrations over10 to 150Hz
Bumps of 6ms
Continuous electrostatic discharge
Electric field
Fast transients at supply
Surge at supply
Emission
*max. analogue deviation of 10%
**50mA in case 3 electronic outputs are used and 150mA in case only one electronic output is used
App 408C
According to Min
18VAC
18VDC
18VDC
18VDC
18VDC
91.9Hz
0mA
IEC 68-2-2B
-10°C
IEC 68-2-14 Na
IEC 68-2-14 Nb
IEC 68-2-3 Ca
IEC 68-2-1 A
IEC 68-2-1 A
-25°C
IEC 68-2-2 B
IEC 68-2-6
IEC 68-2-29
IEC 68-2-6
IEC 68-2-29
IEC 801-2 level
4
IEC 801-3 level
3
Level 4*
IEC 801-4 level
4
IEC 801-5 level
5
Typical
24VAC
20VDC
20VDC
20VDC
50mA**
20VDC
50mA**
43µs
0V
8A (cos phi =1)
16kV
10V/m
30V/m
4kV
3kV
CISPR 22class B
Max
29VAC
22VDC
22VDC
22VDC
150mA**
22VDC
150mA**
11600Hz
20mA
6VDC
250V
+55°C
+65°C
95%
80%
2g
10g
40g
Table 20
98155.1015
