OPERATION
3 way normally closed energise to open, continuous duty.
On starting the solenoid valve opens (energised) this operates the diaphragms which in turn closes
the valves within the D.D.Vs. (Diaphragm Drain Valves) thus allowing pressure to build up in the
system to the desired pressure. On shutdown the solenoid valve closes (de-energised) this takes the
pressure of diaphragms thus allowing the drains to blow any condensate collected within the stage
separators.
Technical Details
Part No
PS2197.1
PS2197.2
PS2197.3
PS2197.4
PS2197.5
PS2197.6
PS2197.7
PS2197.8
PS2197.9
PS2197.10
PS2197.11
PS2197.12
Electrical connection
Connector
Protection
Cable thread size
Coil
Coil duty
Voltage tolerance from normal
Port Size
Orifice Size
Maximum working pressure
Working fluid
Ambient temperature range
CompAir UK Ltd
PUBLICATION APP 138 - 3 WAY SOLENOID VALVES PS2197
3 WAY SOLENOID VALVE
PS2197
INSTALLATION
Voltage
230 50 AC
110 50 AC
220 60 AC
110 60 AC
24
110
230
24 50 AC
12
24 60 AC
125
48 50AC
Amps pin to DIN 46242
To DIN 43650
IP65
PG9
Class 'H' 180°C insulation
Continuous
-10% to +10%
G 1/8"
Ø1.6mm
12 bar g.
Air, water, gas, fuel oil & non corrosive liquids.
-15°C to +50°C
1
0
2
Current consumption
Hz Current Inrush
26 VA
26 VA
26 VA
26 VA
DC -
DC -
DC -
26 VA
DC -
26 VA
DC
26VA
Page 1
Hold
16 VA
16 VA
16 VA
16 VA
10 watts
10 watts
10 watts
16 VA
10 watts
16 VA
10 watts
16VA
