CompAir 5280D.1.IAC Operator's Handbook Manual page 59

CRANKSHAFT CONNECTING ROD
REF. No PART No
1 C10190.754
2 C10500.217
3 C10500.167
4 C10190.32
5 C10190.333
6 C20010.38
7 C10190.208
8 C10190.109
9 C10190.637
10 C10190.764
11 C10190.765
CompAir UK Ltd
5280D Compressor Publication 98407.1440
PARTS LIST
DESCRIPTION
CRANKSHAFT
BALANCE WEIGHT
SCREW
LOCKING PIN
KEY
DRIVING PIN
CONNECTING ROD
BIG END BEARING - HALF
SMALL END BUSH
BOLT
LOCK WASHER
Page 53
No OFF
1
2
4
8
1
2
2
4
4
4
2
1440.doc
