CompAir 5280D.1.IAC Operator's Handbook Manual page 67

REF. No PART No
1 C20011.13
2 C20010.29
3 C20010.41
4 A4330.62
5 A4322.6
6 A3764.4
7 A1442.5
8 C10589.5
9 A4334.53
10 C20011.16
11 C20010.43
12 A4341.76
13 A4322.4
14 A6738.54
15 C20010.30
16 C20010.42
17 A4341.19
18 C20010.35
19 C4241.37
20 A1479.5
21 C20010.39
22 A3770.5
23 A1479.35
24 C20010.37
25 C20011.15
26 A4345.1
27 C10190.412
- C10190.68
- A1479.28
28 C10190.69
CompAir UK Ltd
5280D Compressor Publication 98407.1440
OIL PUMP
PARTS LIST
DESCRIPTION
OIL PUMP
PUMP COVER
JOINT
STUD
NUT
PLUG, BRASS HEXAGON
FIBRE WASHER
PLUG
SCREW
PLATE, BLANKING
LUBRICATOR JOINT
CAPSCREW
NUT
WASHER, SHAKEPROOF
GEAR HOUSING COVER
GEAR HOUSING JOINT
CAPSCREW
PUMP GEAR HOUSING
DOWEL
BUSH
DRIVING GEAR
KEY
BEARING BUSH
DRIVING PLATE
COLLAR, SPACER
SETSCREW
DRIVEN GEAR
GEAR
BEARING BUSH
GEAR SHAFT
Page 61
No OFF
1
1
1
8
8
1
1
1
2
1
1
4
4
4
1
2
6
1
2
1
1
1
1
1
1
2
1
1
2
1
1440.doc
