App 408 Customer PET controller installation guide & user's manual
Page 16
2.2.10 Input configuration
2.2.10.1Analogue calibration
With offsets the display will alternate between the offset and the reading
Parameter
System Setting the offset of the pressure sensor. Sensor trimming
pressure offset must be done when the machine is completely
depressurized. .
Oil pressure Setting the offset of the pressure sensor. Sensor trimming
offset must be done when the machine is completely
depressurized. .
Spare
Cooling water Cooling water temperature offset setting. (Trimming the
temp sensor compared with the real measured temperature).
st st
1 stage dely 1 stage temperature offset setting. (Trimming the sensor
temp. compared with the real measured temperature).
nd nd
2 stage dely 2 stage temperature offset setting. (Trimming the sensor
temp compared with the real measured temperature).
rd rd
3 stage dely 3 stage temperature offset setting. (Trimming the sensor
temp compared with the real measured temperature).
Final air dely Final air temperature offset setting. (Trimming the sensor
temp compared with the real measured temperature).
st
1 stage Setting the offset of the pressure sensor. Sensor trimming
pressure offset must be done when the machine is completely
depressurized. .
nd
2 stage Setting the offset of the pressure sensor. Sensor trimming
pressure offset must be done when the machine is completely
depressurized. .
rd
3 stage Setting the offset of the pressure sensor. Sensor trimming
pressure offset must be done when the machine is completely
depressurized. .
Spare
System press. Configuring the pressure sensor range.
range
Oil press. Configuring the pressure sensor range.
range
st
1 stage press. Configuring the pressure sensor range.
range
nd
2 stage Configuring the pressure sensor range.
press. range
rd
3 stage press. Configuring the pressure sensor range.
range
App 408C
Function Default Min
- - - -100
- - - -100
- - - -10°C +10°C
- - - -15°C +15°C
- - - -15°C +15°C
- - - -15°C +15°C
- - - -10°C +10°C
- - - -100
- - - -100
- - - -100
60 bar 1 bar 71 bar
10 bar 1 bar 17 bar
6 bar 1 bar 17 bar
16 bar 1 bar 26 bar
60 bar 1 bar 71 bar
Table 16
98155.1015
Max
+100
+100
+100
+100
+100
