6.1 GENERAL
Type.
Direction of rotation.
Cooling.
Number of valves first stage.
Number of valves second and third stages.
6.2 TEMPERATURES
Minimum ambient.
Maximum ambient.
maximum water inlet.
Temperature rise across compressor
6.3 OPERATING SPEED
Minimum speed
maximum speed
6.4 INTERNAL DIMENSIONS
Stroke
Cylinder bore - first stage
Cylinder bore - second stage
Cylinder bore - third stage
6.5 LUBRICATION
Crankcase sump capacity
Recommended oils – mineral
Recommended oils - synthetic
6.6 OPERATING PRESSURES
Maximum intake
Minimum intake
Minimum discharge
maximum discharge
Minimum water
Maximum water
Oil pressure when "new"
Minimum oil pressure when "worn"
6.7 PROTECTIVE DEVICE SETTING
Low oil pressure switch setting
Oil pressure regulating valve pressure setting
Control pressure setting
6.8 COOLING
Cooling water flow @ 15 °C inlet
6.9 WEIGHT
Approximate weight of typical compression package
Approximate weight bare compressor
CompAir UK Ltd

LEADING PARTICULARS

Compressor normal operating maximum pressure
5280D Compressor Publication 98407.1440
6
3 stage two cylinder 90 ° Vee.
Clockwise viewed from driving end.
Four suction & four deliver.
One valve per stage.
Shell Corena P100 or Mobil Rarus 427
75 litres/hour per kW power input
Page 15
Water.
0 °C.
45 °C.
37 °C.
10 to 12 °C
350 rev/min
735 rev/min
178 mm
305 mm
220 mm
185 mm
50 litres
Reavellite
atmospheric
atmospheric
20 bar g
50 bar g
0.5 bar g
5.1 bar g
2 bar g
1 bar g
1 bar g
2 bar g
4560 KGs.
2430 KGs.
