CompAir 5280D.1.IAC Operator's Handbook Manual page 113

2.2.10.2 Analogue Input configuration
Function :- Selecting the input signal
Selectable settings
Each input can be selected for the following inputs :- 0-20mA, 0-5V, 4-20mA, 1-5V, 1-6V, 5-55V, KTY10,
KTY10B, PT1000, Off
Input No.
1
2
3
4
5
6
7
8
9
10
11
12
Note: Apart from setting a software parameter in this menu, hardware jumpers have to be set as well
according to the selected input signal. A detailed description regarding the jumper settings for the
standard version is given in 3.11.
2.2.10.3 Digital input configuration
Note:- The default values for 4-6, 10-12 and 14-16 are set to NO to alleviate the need for fitting a link if a
trip is not fitted. However if a trip is fitted, then it should be operated in the NC mode and the corresponding
digital input changed to NC. The water flow is also optional but is set in the opposite sense as it is assumed
no flow occurs in the stopped state.
Input No
1 Emergency stop A
2 Motor current
3 Water flow
4 Fault A
5 Fault B
6 Fault C
7 Remote stop/start
8 Motor temperature (PTC)
9 Emergency stop B
10 Fault D (time delayed)
11 Fault E (time delayed)
12 Fault F (time delayed)
13 Remote load/unload
14 Water pump overload
15 Suction filter delta P
16 Fan motor overload
Note: NO = Normal open, NC = Normal closed
