CompAir 5280D.1.IAC Operator's Handbook Manual page 71

REF. No PARTS No
1 C20010.23
2 C11058.6
3 C11003.24
4 A4338.19
5 C20010.7
6 C20010.8
7 C20010.14
8 A4335.51
9 A4335.53
10 C11003.12
11 C11003.8
12 C11003.7
13 A4334.204
14 C11003.11
15 C11003.13
16 A4338.23
17 A4341.179
18 C20010.71
19 C3637.5
20 A4337.51
21 C11003.27
22 A3803.4
23 A3803.9
CompAir UK Ltd
5280D Compressor Publication 98407.1440
INTERCOOLER
PARTS LIST
DESCRIPTION
INTERCOOLER
END COVER
END COVER JOINT
BOLT
BODY INTERCOOLER
BOTTOM COVER
JOINT
HEX HD SCREW
SCREW
COVER JOINT
INNER HEAD COVER
COVER JOINT
HEX HD SCREW
OUTER HEAD COVER
HEAD COVER JOINT
BOLT
CAPSCREW
FLANGE
JOINT
BOLT
TUBE ELEMENT
DRAIN COCK
VENT COCK
Page 65
No OFF
1
1
1
10
1
1
1
8
4
1
1
1
12
1
1
10
2
1
1
2
1
1
1
1440.doc
