Programming Examples
-> LIST ON or FUNC:MODE LIST
To turn the output on, send the command:
-> OUTP ON
When the trigger source is set to BUS, send the following command to generate
a trigger:
-> TRIG

Example4: Battery Charging Test Function

Before running the battery charging test function, the bleeder circuit function
must be disabled by sending the command:
-> BLE OFF
To specify manual trigger，BUS trigger or external trigger for the trigger source,
send the command:
-> TRIGger:SOURce KEYPad|BUS|EXT
To set the charging voltage to 5 V, send the command:
-> BATT:CHAR:VOLT 5.0
To set the charging current to 3 A, send the command:
-> BATT:CHAR:CURR 3.0
To set the charging time to 3 seconds, send the command:
-> BATT:STOP:TIME 3.0
To set the cut off voltage to 4 V, send the command:
-> BATT:STOP:VOLT 4.0
To set the cut off current to 3 A, send the command:
-> BATT:STOP:CURR 3.0
To set the cut off capacity to 3 AH, send the command:
-> BATT:STOP:CAP 3.0
To enable the battery charging test function, send the command:
-> BATT ON or FUNC:MODE BATT
To turn the output on, send the command:
-> OUTP ON
